RECX.570

$107.50

Digital Rectifier + Regulator.

  • New gen Open-Drain design
  • 570w max output power
  • Trench type MOSFET design
  • Multi-phase stator compatible
  • Ultra fast switching digital regulator
  • Low heat operation
  • Solid state design for water proof & shock proof operation
  • Permanent magnet & field coil stator capable
  • Lead acid de-sulphate feature
  • Lead acid/AGM/lithium battery type compatible
  • Steady output voltage 14.25v
  • Include wire connectors & mounting hardware
  • Any orientation installation mounting
  • Designed for TC3 & X3 control hub
  • 1 year replacement warranty

In stock

SKU: RECX.570
Category:
Tags: ,

What makes this unit special isn’t just the specs — it’s the open‑drain design that protects your stator. Traditional regulators can run hot and stress the stator over time, leading to costly repairs or replacements that are often bike‑specific and hard to source. Our digital regulator/rectifier flips that script: it runs cooler, bleeds off excess power safely, and keeps your stator working longer. In short, it’s engineered to save you money, extend the life of your charging system, and keep you riding instead of wrenching.

  • Stator protection first: The most expensive part of the system is spared unnecessary wear.
  • Cool operation: Less heat means longer life for both regulator and stator.
  • Customer‑first design: Built to solve the real pain point riders face — stator failure.
Weight 388.62 g
